ADI 4-20mA電壓環路數模切換器

正式發布精力：2022-03-24 16:34:54     瀏覽網頁：1919

ADI集合系統的解決方法方法將數模換算器和驅使器集合到有一個基帶芯片中，行單獨從阿拉伯數字域提供數據必需要的輸入。ADI的工業企業數模轉變成器和控制器護膚品款型作為常見的可編寫程序輸入輸出，從感應電流量電路無線通訊的標淮4mA到20mA到管控閥調控的±10V。ADI產業換為器帶來高品質的調用和技術領先的片上初步判斷，以明顯局限性地曾加整體的正確工作期限，嚴防有些一般式離散工作體系形式一般而言需的寶貴的多個標定過程。

遠距離臨床診斷和程序故障率化解給出超額數據庫，以提高自己程序的安全可靠性完好性技巧。ADI可以提供了多多面的HART調配解調器和4mA到20mA互轉器，能否直接在使用，以控制穩定的性，高精度和HART私募促進會祖冊的應對方案格式。ADI的處理運輸方案需要充分考慮環路和非環路輸電線路壓力變送器、隔絕和非隔絕仿真I/O卡的標準規定的要求。

成都 市立維創展社會是ADI的分銷模式商，基本供給擴大器、波形產品、統計資料轉型器、音頻視頻播放產品、網絡帶寬產品、鐘表和要定期IC、金屬通信網軟件、usb接口和時間間隔、MEMS和感應器器、交流電源和熱經管、加工電腦處理器和DSP、微波射頻和圖型加工器、旋鈕和配置器等。大局部廠品，均能提供現貨交易存量供貨商。

商品詳情頁分析ADI芯片請點擊：//www.zb5858.cn/brand/25.html


新產品具體型號

ChannelsResolutionDAC TypeTUE Iout (typ)Output RangeDAC FeaturesSupply Voltage Range


bits
%


AD5423116Current Out, Voltage Out
±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, 0 to   5V, -0.3V to 5.7V, -0.4V to 11.6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to   12V, -1mA to 22mA, 4mA to 20mA4-20mA, HART Connectivity-33V to +33V
AD74412R416Current Out, Voltage Out0.20mA to 25mA, 0V to 11V4-20mA14V to 26.4V, 2.7V to 5.5V
AD74413R416Current Out, Voltage Out0.20mA to 25mA, 0V to 11V4-20mA14V to 26.4V, 2.7V to 5.5V
AD5413114Current Out, Voltage Out
±10.5 V, ±12.6 V, 0mA to 24mA4-20mA, HART Connectivity-33V to +33V
AD5758116Current Out, Voltage Out
±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, 0mA   to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, 0V to 5V, 0V to 6V, -1mA to 22mA,   4mA to 20mA4-20mA, DAC, Dynamic Power Control, HART   Connectivity, Integrated ADC, LDAC Pin-33V to 0V, 5V to 33V, 7V to 33V
ADFS5758116Current Out, Voltage Out
±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, -0.3V   to 5.7V, -0.4V to 11.6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, 0V   to 5V, 0V to 6V, -1mA to 22mA4-20mA, DAC, Functional Safety, HART   Connectivity, Precision DACs-12V to -24V, -33V to +33V
AD5735412Current Out, Voltage Out0.022±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, LDAC   Pin, Read-Back, Reset/Clear, SDO Pin-26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V
AD5737412Current Out0.0220mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, HART   Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin2.7V to 5.5V, 4.5V to 5.5V, 9V to 33V
AD5755416Current Out, Voltage Out0.009±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, LDAC   Pin, Read-Back, Reset/Clear, SDO Pin-26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V
AD5755-1416Current Out, Voltage Out0.009±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, HART   Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin-26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V
AD5757416Current Out0.0090mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, HART   Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin4.5V to 5.5V, 9V to 33V
AD5421116Current Out0.0643.2mA to 24mA, 3.8mA to 21mA, 4mA to 20mA4-20mA, Double-Buffered, LDAC Pin, On   Chip Temp Sensor, Read-Back, SDO Pin5.5V to 52V
AD5410112Current Out0.080mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, Daisy Chain, HART Connectivity,   LDAC Pin, Read-Back, Reset/Clear, SDO Pin10.8V to 60V
AD5412112Current Out, Voltage Out0.08±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, Daisy Chain, HART Connectivity,   LDAC Pin, Read-Back, Reset/Clear, SDO Pin10.8V to 40V, -26.4V to 0V
AD5420116Current Out0.080mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, Daisy Chain, HART Connectivity,   LDAC Pin, Read-Back, Reset/Clear, SDO Pin10.8V to 60V
AD5422116Current Out, Voltage Out0.08±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, Daisy Chain, LDAC Pin, Read-Back,   Reset/Clear, SDO Pin10.8V to 40V, -26.4V to 0V
AD421116Current Out
4mA to 20mA4-20mA2.95V to 5.05V
AD420116Current Out, Voltage Out
±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA12V to 32V
