Voltage

90~264 VAC or 120~370 VDC

Frequency

47-63 Hz

Inrush Current (<500us)

20 A  (115 VAC) /
50 A  (230 VAC)

(max.)

Leakage Current

0.25 mA

(max.)

Output Specifications / 輸出規格

Power

3

(max.)

Voltage

3.3, 5, 9, 12, 15, 24

Voltage Accuracy
(Full Load and Nominal Vin)

±10%

Minimum Load

0% (at Full Load)

Line Regulation
(LL to HL at Full Load)

3.3S:±5%
---------------------------------
others:±2%

(typ.)

Load Regulation
(0% to 100% at Full Load)

3.3S:±5%
---------------------------------
others:±2%

(typ.)

Ripple & Noise

3.3S:<250mV (Vp-p)
---------------------------------
5S:<200mV (Vp-p)
---------------------------------
9S:<150mV (Vp-p)
---------------------------------
12S,15S,24S:<100mV (Vp-p)

(max.)

Protection / 保護規格

Over Power Protection

Hiccup technique, auto-recovery

Over Voltage Protection

Zener diode clamp

Short Circuit Protection

Hiccup mode,
indefinite (automatic recovery)

Operating Temperature

-40 °C to +85 °C

Storage Temperature

-40 °C to +85 °C

Temperature Coefficient

±0.02% / °C

Humidity

95% RH

SAFETY & EMC

Isolation Voltage
(Input to Output)

3750 VAC

Agency Approvals

UL / IEC / EN 60950-1

EMI
(Conducted & Radiated Emission)

EN 55032 class B

EMS
(Noise Immunity)

EN 55024

Others / 另外的

Dimensions
(Tolerance ±0.5mm)

35.7 x 19.0 x 22.0 mm
1.41 x 0.75 x 0.86 inches

Weight

19.9 g

Case Material

Plastic resin with Fiberglass
(flammability to UL 94V-0)

Cooling Method

Free air convection
