V48SD05024NNFH隔離電源模塊1/16磚120W

更重要性能

輸入電壓：36-60V

讀取電流電壓： 5.0V/ 12V業務功率：10A/24A效果：93%封口體積太：33*22.8*9.2mm定貨生長期： 6-8周

類產品詳情頁解紹

Electrical

? High efficiency: 91.9% @ full load

? Fixed frequency operation

? Input UVLO, OTP and output OCP, OVP

? Output voltage trim: max 20%

? Pre-biased startup

? 2250V isolation and basic insulation

?Applied to altitude up to 5000m

Mechanical

? Open-frame: Size: 33.0mm(L)x22.8mm(W)x9.2mm(H)

? With heat spreader: Size: 33.0mm(L)x22.8mm(W)x12.2mm(H)

Safety & Reliability

? IEC/EN/UL/CSA 62368-1, 2nd edition

? ISO 9001, TL 9000, ISO 14001, QS 9000, OHSAS18001 certified manufacturing facility
